基板クイック試作
カスタム基板試作サービス
基板クイック試作
カスタム基板試作サービス
Ultra-high-speed PCB gold finger board, this type of circuit board is made of Taiyao TU-872SLK + Rogers RO4350b high-speed material, produced by mixed pressure, high-end CNC mechanical drilling, surface immersion gold, gold finger thick gold plating and other processes, the smallest The aperture can reach 0.2mm, the Min Track/Spacing can reach 127/75um, and the gold-plated thickness of the gold finger can reach 30u. This type of high-speed PCBis widely used in the field of high-speed computer boards.
14 layers, Material: IT170GRA1TC, Thickness: 1.6±0.05mm
10 layers, Material: IT968TC+S1000-2M, Thickness: 1.0±0.1mm
4 layers, Material: RO4350B+TU768, Thickness: 1.6±0.16mm
お問い合わせ!
私達のカスタマーサービス+86-571-85317532
Final version of my control PCB for turnout motor, indicator leds, and pushbuttons. You need one of these boards per turnout. Production process was fast and smooth. Shipping was also flawless. Thanks a lot, PCBWay !!!
Engineer
It's a heart-shaped PCB based on https://github.com/fellettigiacomo/NeoHeart but I reduced the number of LEDs and added a MAX30102 sensor to read the users's heartbeat and pulse the onboard LEDs accordingly. Sierra was in charge of overseeing the assembly and they did a pretty good job, I am very happy, everything is working correctly and they took every measure they could to ensure that because they reached out to me multiple times for confirmation.
Treviño Cervantes
